Meenyon Electric Pallet Truck DB3 1.5t Electric Pallet Jack
Product selling point
- Small body;
- Light weight;
- High efficiency;
- Easy to maintain;
- More stable
Small body: Almost the same size as a hand truck
Light weight: The vehicle weighs 135kg, which is no more than a hand truck.
High efficience: Equivalent to 3 hand trucks
| Item | Name | Unit | |
|---|---|---|---|
| Feature | |||
| 1.1 | Brand | MEENYON | |
| 1.2 | Model | DB3 | |
| 1.3 | Power | Electric | |
| 1.4 | Operation | Walking | |
| 1.5 | Rate load | Q(kg) | 1500 |
| 1.6 | Load center distance | C(mm) | 600 |
| Weight | |||
| 2.1 | Dead weight (Incl. battery) | kg | 135 |
| Tires,Chassis | |||
| 3.2 | Front wheel size(diameter×width) | Ф210x70 | |
| Size | |||
| 4.4 | Standard max lifting height | h3(mm) | 110 |
| 4.15 | Fork drop height | h13(mm) | 80 |
| 4.19 | Overall length | l1(mm) | 1580 |
| 4.21 | Overall width | b1/b2(mm) | 560(685) |
| 4.25 | Fork outside distance | b5(mm) | 560(685) |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2175 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2080 |
| 4.35 | Turning radius | Wa (mm) | 1360 |
| Performance parameter | |||
| 5.1 | Walk speed, full/no load | km/ h | 4/4.5 |
| 5.8 | Max climb, full/no load | % | 5/16 |
| Motor, Power unit | |||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 24/45 |
Features
◆Lightweight structure: This electric pallet truck is designed with high-strength and lightweight materials. The weight of the whole vehicle is only 0.135t, which is equivalent to a trolley, making it easier for operators to move in a small space and simpler to maintain
◆High operating efficiency: The overall design of the electric pallet truck is lighter, but it can carry an operating weight of 1.5t, which is equivalent to three trolleys
◆More stable: The chassis design and tire material of this electric pallet truck have been optimized to ensure stable operation under uneven or worse ground conditions, improving the safety and reliability of cargo loading and unloading operations.
Application:
◆Warehousing and logistics: Suitable for short-distance transportation in warehouses to improve operating efficiency
◆Retail and wholesale center: The overall lightweight design facilitates flexible operation between shelves and reduces manual labor intensity.
FAQ
Q: How does the lightweight design of this electric pallet truck benefit operators in a small space?
A: High-strength and lightweight materials make the whole vehicle as easy to control as a trolley. This allows the operator to effortlessly navigate narrow aisles and tight spaces, increasing efficiency and reducing physical strain during operation.
Q: Despite its lightweight design, can this electric pallet truck handle heavy loads?
A: Yes, despite its lightweight construction, this electric pallet truck has three times the load capacity of a traditional trolley. This combination of portability and strength makes it ideal for tasks that require mobility and heavy lifting.
Q: How does the optimized chassis and tire design improve safety when loading and unloading goods?
A: The chassis and tires are specially designed to ensure stable operation on uneven or complex surfaces. This improves safety and reliability when loading and unloading, reduces the risk of accidents, and ensures smoother operation in challenging environments.
