Company Advantages
· Meenyon forklift wholesalers is accurately manufactured by using the industry-leading technology and the sophisticated equipment.
· The product is put into the market after rigorous inspection.
· The product has long been known and well accepted in the industry for its extremely reliable performance.
Product specifications
| Item | Name | Unit (Code) | |
| Feature | |||
| 1.1 | Brand | MEENYON | |
| 1.2 | Model | ES08-WAI | |
| 1.3 | Power | Electric | |
| 1.4 | Operation | Walking | |
| 1.5 | Rated load | Q (kg) | 800(Fork load2000) |
| 1.6 | Load center distance | c (mm) | 600 |
| Weight | |||
| 2.1 | Dead weight (incl. battery) | kg | 660 |
| Size | |||
| 4.2 | Lowest height after the gantry is lowered | h1 (mm) | 1860 |
| 4.4.. | Gantry travel | h3 (mm) | 1480 |
| 4.4... | Gantry lifting height (fork face to ground) | h23 (mm) | 1685 |
| 4.15 | Fork drop height | h13(mm) | 95 |
| 4.19 | Overall length | l1 (mm) | 1776 |
| 4.21 | Overall width | b1/ b2 (mm) | 738 / 710 |
| 4.25 | Fork outside distance | b5 (mm) | 560 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2274 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2198 |
| 4.35 | Turning radius | Wa (mm) | 1442 |
| Performance parameter | |||
| 5.1 | Travel speed, full / no load | km/ h | 5 / 5.5 |
| 5.2 | Max climb, full / no load | m/ s | 0.14/0.2 |
| Motor, Power unit | |||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 4*6v/224Ah |
Company Features
· With highly advanced production equipment, Meenyon is globally prestigious in forklift wholesalers sector.
· We have teams of talented staff. They are able to help craft the perfect design, integrating customers' brand into the visual aesthetic of the product.
· We aim to continuously find innovative ways to reduce energy consumption, eliminate waste, and reuse materials to minimize our impact on the environment and develop a sustainable footprint.
Product Details
We are confident about the exquisite details of forklift wholesalers.
Application of the Product
Meenyon's forklift wholesalers can be widely used in various fields.
With rich manufacturing experience and strong production capability, Meenyon is able to provide professional solutions according to customers' actual needs.
Product Comparison
Compared with its peer products, forklift wholesalers produced by Meenyon has the following advantages.
