Product specifications
Item | Name | Unit (Code) | |
Feature | |||
1.1 | Brand | MEENYON | |
1.2 | Model | RSB151Z | |
1.3 | Power | Electric | |
1.4 | Operation | Walking | |
1.5 | Rated load | Q (kg) | 1500 |
1.6 | Load center distance | c (mm) | 600 |
Weight | |||
2.1 | Dead weight (incl. battery) | kg | 770 |
Size | |||
4.2 | Lowest height after the gantry is lowered | h1 (mm) | 1970 |
4.4 | Standard max lifting height | h3 (mm) | 2915 |
4.15 | Fork drop height | h13(mm) | 85 |
4.19 | Overall length | l1 (mm) | 1754 |
4.21 | Overall width | b1/ b2 (mm) | 800 |
4.25 | Fork outside distance | b5 (mm) | 570/685 |
4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2330 |
4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2300 |
4.35 | Turning radius | Wa (mm) | 1455 |
Performance parameter | |||
5.1 | Travel speed, full / no load | km/ h | 5 / 5.5 |
5.2 | Max climb, full / no load | m/ s | 0.10/0.18 |
Motor, Power unit | |||
6.4 | Battery voltage/nominal capacity | V/ Ah | 48/85 |
Company Advantages
· The innovative design of Meenyon electric forklift trucks for sale leaves a lasting impression on the customers.
· The careful inspection during production greatly guarantees the overall quality of the product.
· Providing high-quality electric forklift trucks for sale products for customers is Meenyon' s commitment.
Company Features
· Meenyon ranks among the top leaders in the domain of developing and manufacturing electric forklift trucks for sale. We have recognized manufacturing strength.
· Meenyon has a professional R&D base for developing high quality electric forklift trucks for sale.
· For a greater goal of being an influential electric forklift trucks for sale supplier, Meenyon has been seeking for greater perfection since founded. Contact us!
Application of the Product
The electric forklift trucks for sale produced by our company is suitable for various occasions in industry.
We understand the actual situation of the market, and then combine the needs of customers. In this way, we develop the most suitable solutions for customers and effectively meet their needs.
