Company Advantages
· Meenyon electric pedestrian stacker has a design that satisfies design standard.
· The product is tested to be of the highest quality again and again.
· The product has a wider and wider market thanks to its above advantages.
Product specifications
| Item | Name | Unit (Code) | |
| Feature | |||
| 1.1 | Brand | MEENYON | |
| 1.2 | Model | ES15-33DM | |
| 1.3 | Power | Electric | |
| 1.4 | Operation | Walking | |
| 1.5 | Rated load | Q (kg) | 1500 |
| 1.6 | Load center distance | c (mm) | 600 |
| Weight | |||
| 2.1 | Dead weight (incl. battery) | kg | 915 |
| Size | |||
| 4.2 | Lowest height after the gantry is lowered | h1 (mm) | 2128 |
| 4.4 | Standard max lifting height | h3 (mm) | 3220 |
| 4.15 | Fork drop height | h13(mm) | 60 |
| 4.19 | Overall length | l1 (mm) | 1650 |
| 4.21 | Overall width | b1/ b2 (mm) | 1270/1370/1470 |
| 4.25 | Fork outside distance | b5 (mm) | 200~765 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2250 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2200 |
| 4.35 | Turning radius | Wa (mm) | 1400 |
| Performance parameter | |||
| 5.1 | Travel speed, full / no load | km/ h | |
| 5.2 | Max climb, full / no load | m/ s | 0.14/0.2 |
| Motor, Power unit | |||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 24/125 |
Company Features
· Meenyon has strong strength in the international electric pedestrian stacker market.
· New technologies have been applied to the production for electric pedestrian stacker. We are at the core competitiveness of electric pedestrian stacker production line technology. electric pedestrian stacker is produced by our modern production line and tested by our experienced technicians.
· Meenyon plans to enter into the global market through providing exquisite electric pedestrian stacker and exceptional service. Call!
Product Details
We will show you more detailed information of electric pedestrian stacker.
Application of the Product
The electric pedestrian stacker produced by Meenyon is widely used in many industry sectors.
Based on customers' specific situations and needs, Meenyon provides comprehensive and reasonable solutions.
Product Comparison
Compared with its peer products, electric pedestrian stacker produced by Meenyon has the following advantages.
