Company Advantages
· Supported by highly proficient workers, Meenyon electric forklift pallet truck is delicately crafted and has an aesthetically-pleasing appearance.
· The quality of the product meets the latest industry standards.
· Meenyon establish far more high standards for electric forklift pallet truck quality.
Pull the battery sideways to replace the battery, and the power comes in instantly.
(Optional battery capacity)
1. The whole vehicle adopts the high-strength box-type frame of an internal combustion vehicle, which can meet the harsh outdoor working conditions.
2. The entire vehicle is IPX4 waterproof and supports all-weather use indoors and outdoors.
3. High ground clearance, can go off-road, and can easily pass through uneven potholes.
4. Wide field of view mast, good front working field of view, does not affect driving sight, making operation efficient and safe
It has strong load capacity and can meet the needs of 3.8 tons heavy cargo handling in the logistics park.
It uses lower carbon, cleaner and more environmentally friendly lithium electric power. Compared with internal combustion vehicles, it has low noise, no dirty exhaust gas, and no acid mist. It meets the needs of indoor use and is beneficial to the health of employees.
1. The reinforced mast is adopted, the rollers are improved, the material is thicker, the load capacity is stronger, and the overall performance is good.
2. The vehicle has a low center of gravity and strong stability, and is suitable for handling goods with large load center distances and attachment operations.
3. Use mature front and rear axles, lifting hydraulics and control systems and other common parts for internal combustion vehicles, which are strong and durable.
4. The entire vehicle is equipped with parking, emergency power-off and other protections for safe driving.
1. The engine cover can be opened at a wide angle for easy maintenance and battery replacement.
2. Lithium batteries are maintenance-free and require less maintenance costs.
3. 5-year lithium battery warranty, lithium iron phosphate battery is highly safe
1. Taking advantage of the lithium battery, the driving space is large and the operation is comfortable.
2. The steering wheel is adjustable to suit drivers with different body shapes and operating habits.
3. The steering system has been finely adjusted, making the turns smooth.
COMPANY STRENGTH
| Item | Name | Unit | |||
|---|---|---|---|---|---|
| Feature | |||||
| 1.1 | Brand | MEENYON | MEENYON | MEENYON | |
| 1.2 | Model | EFX302H Lithium | EFX352H Lithium | EFX382H Lithium | |
| 1.3 | Power | Electric | Electric | Electric | |
| 1.4 | Operation | Car type | Car type | Car type | |
| 1.5 | Rated load | Q (kg) | 3000 | 3500 | 3800 |
| 1.6 | Load center distance | c (mm) | 500 | 500 | 500 |
| Weight | |||||
| 2.1 | Dead weight (incl. battery) | kg | 4530 | 4745 | 5210 |
| Tires, chassis | |||||
| 3.1 | Tire type, drive wheel/carrier wheel (steering wheel) | Pneumatic tire | Pneumatic tire | Solid tire | |
| Size | |||||
| 4.4 | Max lifting height of frame | h3 (mm) | 3000 | 3000 | 3000 |
| 4.7 | Top guard (cab) height | h6 (mm) | 2160 | 2190 | 2190 |
| 4.20 | Length to vertical face of fork | l2 (mm) | 2726 | 2765 | 2800 |
| 4.21 | Overall width | b1/b2 (mm) | 1230 | 1230 | 1230 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 4170 | 4216 | 4256 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 4370 | 4416 | 4456 |
| 4.35 | Turning radius | Wa (mm) | 2484 | 2530 | 2570 |
| Performance parameter | |||||
| 5.1 | Travel speed, full / no load | km/ h | 11/12 | 11/12 | 15/16 |
| 5.8 | Max climb, full / no load | % | 18/24 | 17/23 | 16/20 |
| Motor, Power unit | |||||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 80/280 | 80/280 | 80/280 |
Company Features
· Meenyon is a senior company classified as producing electric forklift pallet truck.
· Our big and wide factory is well-organized inside in a thorough manner. It includes various kinds of advanced machines, which allows us to smoothly finish our production projects. Over the years, we have built up a solid customer base and group. These customers include small manufacturers and some of the robust and renowned companies, which contributes to the growth of our business.
· MEENYON aims to create Meenyon as the electric forklift pallet truck industry's first brand. Call!
Product Details
In order to strengthen your understanding of electric forklift pallet truck, Meenyon will show you the specific details of electric forklift pallet truck in the following section.
Application of the Product
The electric forklift pallet truck produced by our company can be applied to different fields and scenarios. So the different requirements of different people can be satisfied.
Meenyon is able to meet customers' needs to the greatest extent by providing customers with one-stop and high-quality solutions.
Enterprise Advantages
Meenyon has a professional team integrates management, R&D, production, inspection, marketing, and after-sales service. This lays a solid foundation for the development.
Meenyon abides by the service concept that we always put customers' satisfaction first. We strive to provide professional consulting and after-sales services.
Our company strives to provide high-value products and services for the society, based on the spirit of 'passion, innovation, hard work'. We operate our business by sticking to integrity management and we believe that cooperation brings mutual benefit.
After years of development, Meenyon is expanding and is on the way to become an industry leader.
Our company has vigorously explored the domestic and overseas markets through various means. Currently, the products are successfully entered into some countries and regions in Europe, America and Australia.
