Electric Pallet Jack for Sale Factory
Product details of the electric pallet jack for sale
Product Information
Meenyon electric pallet jack for sale is attractive in the industry for its appealing designs. This product is thoroughly tested on various stages by our quality controllers as per the set industrial norms. This product has helped promote the realization of sustainable value growth for customers.
Introduction
The electric pallet mover is an innovative material handling solution designed to streamline the transportation of heavy loads in warehouses, distribution centers, and manufacturing facilities. This versatile piece of equipment combines the functionality of a traditional pallet jack with advanced electric power capabilities, allowing operators to effortlessly lift and maneuver pallets weighing thousands of pounds with minimal physical exertion. Equipped with durable wheels and a robust frame, the robot pallet mover enhances mobility while promoting workplace safety by reducing the risk of strain injuries.
Five new models of intelligent transportation, striving to create Industrial Logistics 4.0
Competitive Edge
Four Core Characteristics
COMPANY STRENGTH
|
Item |
Name |
Unit (Code) |
|
| Feature | |||
| 1.1 | Brand | MEENYON | |
| 1.2 | Model | XP2-201 | |
| 1.3 | Power | Electric | |
| 1.4 | Operation | Standing | |
| 1.5 | Rated load | Q (kg) | 2000 |
| 1.6 | Load center distance | c (mm) | 600 |
| Weight | |||
| 2.1 | Dead weight (incl. battery) | kg | 407 |
| Tires, chassis | |||
| 3.1 | Tire type, drive wheel/carrier wheel (steering wheel) | polyurethane | |
| 3.2 | Front wheel size (diameter × width) | Φ230×75 | |
| Size | |||
| 4.4. | Standard max lifting height | h3 (mm) | 110 |
| 4.9 | Minimum/maximum height of operating position handle lever | h14 (mm) | 1195 |
| 4.15 | Height of fork after lowering | h13(mm) | 90 |
| 4.19 | Overall length | l1 (mm) | 1695 |
| 4.20. | Length of the vertical surface of the delivery fork | l2 (mm) | 560 |
| 4.21 | Overall width | b1/ b2 (mm) | 825 |
| 4.22 | Fork size | s/ e/ l (mm) | 55x170x1150 |
| 4.25 | Fork outer width | b5 (mm) | 540/600/685 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2365 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2225 |
| 4.35 | Turning radius | Wa (mm) | 1565 |
| Performance parameter | |||
| 5.1 | Walk speed, full/no load | km/ h | 5.5/6 |
| 5.2 | Lifting speed, full/no load | m/ s | 0.023/0.030 |
| 5.3 | Descending speed, full/no load | m/ s | 0.032/0.029 |
| 5.8 | Max climb, full/no load | % | 8.0/16.0 |
| 5.10. | Service brake type | electromagnetism | |
| Motor, Power unit | |||
| 6.1 | Rated power of drive motor S2 60min | kW | 1.5 |
| 6.2 | Rated power of lifting motor S3 15% | kW | 0.84 |
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 24/120 |
| Drive/lifting mechanism | |||
| 8.1 | Drive Control Type | Exchange | |
| Other parameters | |||
| 10.5 | Steering type | Electron | |
| 10.7 | Noise level | dB (A) | 74 |
Company Advantage
• We will have specially-assigned people to pay a return visit to the customer regularly, and make improvement in the first time according to the customer's opinions.
• Meenyon has a sales network covering the whole country. Some products are exported to America, Africa, Europe, and other countries and regions. Now we are an influential company in the industry.
• Our company has obvious advantages in location and the transportation is convenient, laying a good foundation for the development.
• Our company was founded in and our business scope has been expanding continuously. However, our product quality will always stay the same. And we are ready to provide more quality products for consumers wholeheartedly.
• Meenyon has a professional team with experienced team members. Besides, we introduce international advanced production concepts and models to promote corporate development.
If you have any interest in Meenyon's leatherware, please feel free to contact us. We look forward to your communication and cooperation.
