Electric Power Stacker Factory Direct Supply
Product details of the electric power stacker
Product Description
In the production of Meenyon electric power stacker, the superior material is applied properly. The installation of electric power stacker system is much more convenient than other equipment. MEENYON has found its growing popularity and acceptance among overseas customers.
Product selling points
Key points
Application
COMPANY STRENGTH
|
Item |
Name |
Unit (Code) |
|
| Feature | |||
| 1.1 | Brand | MEENYON | |
| 1.2 | Model | ESR151 | |
| 1.3 | Power | Electric | |
| 1.4 | Operation | Standing | |
| 1.5 | Rated load | Q (kg) | 1500 |
| 1.6 | Load center distance | c (mm) | 500 |
| Weight | |||
| 2.1 | Dead weight (incl. battery) | kg | 670 |
| Size | |||
| 4.2 | Lowest height after the gantry is lowered | h1 (mm) | 2106 |
| 4.4 | Gantry travel | h3 (mm) | 3016 |
| 4.4... | Gantry lifting height (fork face to ground) | h23(mm) | 2930 |
| 4.15 | Fork drop height | h13(mm) | 90 |
| 4.19 | Overall length | l1 (mm) | 1832 |
| 4.21 | Overall width | b1/ b2 (mm) | 850 |
| 4.25 | Fork outside distance | b5 (mm) | 570 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2328 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2262 |
| 4.35 | Turning radius | Wa (mm) | 1488 |
| Performance parameter | |||
| 5.1 | Walk speed, full/no load | km/ h | 4.0/4.5 |
| 5.2 | Lifting speed, full/no load | m/ s | 0.10/0.14 |
| Motor, Power unit | |||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 24/105 |
Company Feature
• Our company is close to the road with convenient transportation. It facilitates the transportation of products and guarantees the timely supply of products.
• Meenyon's sales network now covers many provinces and cities such as Northeast China, North China, East China, and South China. And our products are highly praised by consumers.
• Meenyon was founded in We have actively extended supply chain and have striven to strengthen the organic connection between R&D, production, processing, sales, and service. After years of exploration, we run a business with a certain scale.
• Meenyon's initial intention is to provide service that can bring customers comfortable and secure experience.
• Our company has established a high-quality and high-efficiency production team. With years of production experience, our members can solve problems in the process of production effectively.
Welcome to Meenyon. Feel free to contact us if you have any questions.
