Meenyon offers professional OEM & ODM services for all kinds of electric forklift, electric pallet truck, electric stacker and diesel forklift.

Electric Walkie Straddle Stacker by Meenyon 1
Electric Walkie Straddle Stacker by Meenyon 2
Electric Walkie Straddle Stacker by Meenyon 3
Electric Walkie Straddle Stacker by Meenyon 1
Electric Walkie Straddle Stacker by Meenyon 2
Electric Walkie Straddle Stacker by Meenyon 3

Electric Walkie Straddle Stacker by Meenyon

Inquiry
Send your inquiry

Company Advantages

· The materials are the soul of Meenyon electric walkie straddle stacker and well-selected from top grade suppliers. These materials perform well in the whole lifespan of the product.

· The new features of area of electric walkie straddle stacker would make it highly marketable.

· At this point, Meenyon has established a huge friendly and mutually beneficial marketing network throughout the world.

Product selling points

Electric Walkie Straddle Stacker by Meenyon 4
Safer
Electric Walkie Straddle Stacker by Meenyon 5
Cost-effective
31
High performance
25
Easy to operate and maintain

Key points

◆ Outstanding reliability: High strength structure, mature drive and hydraulic system, reliable connectors and electrical parts

◆ Safe and secure: Fully anti-rollover tested, explosion-proof design of hydraulic system, automatically switches to slow speed mode after the forks raise to 720mm.

◆ Easier operation:Long handle, with independently developed handle mechanical spring structure, light operation, flexible steering;

Offset operation, greatly improve the operating field of view.

◆ Easier maintenance: Maintenance-free battery, automatic low voltage protection, self-diagnosis system

6974564(4)
765464(3)

Application

◆ Small to Medium Workspaces: Ideal for performing stacking tasks in smaller warehouses or manufacturing facilities, providing an economical solution for material handling.

◆ Safety and Stability: Designed to offer high stability and safety, making it a hassle-free option for daily material handling needs.


3-xj3
3-xj3
3-xj4
3-xj4
3-xj5
3-xj5

COMPANY STRENGTH

Item Name Unit (Code)
Feature
1.1 Brand   MEENYON
1.2 Model   EST122
1.3 Power   Electric
1.4 Operation   Walking
1.5 Rated load Q (kg) 1200
1.6 Load center distance c (mm) 600
Weight
2.1 Dead weight (incl. battery) kg 585
Size
4.2 Lowest height after the gantry is lowered h1 (mm) 1856
4.4 Standard max lifting height h3 (mm) 2430
4.15 Fork drop height h13 (mm) 85
4.19 Overall length l1 (mm) 1713
4.21 Overall width b1/ b2 (mm) 792
4.25 Fork outside distance b5 (mm) 570
4.34.1 Pallet 1000 × 1200 cross path width Ast (mm) 2290
4.34.2 Pallet 800 × 1200 cross path width Ast (mm) 2225
4.35 Turning radius Wa (mm) 1458
Performance parameter
5.1 Travel speed, full / no load km/ h 4.2/4.5
5.2 Lifting speed, full /no load m/ s 0.10/0.14
Motor, Power unit
6.4 Battery voltage/nominal capacity V/ Ah 24/80


Company Features

· Meenyon is a manufacturer that specializes in providing overseas markets with electric walkie straddle stacker.

· Every electric walkie straddle stacker undergoes detailed tests to verify quality and functionality. To allow customers to better enjoy electric walkie straddle stacker, many advanced technologies are applied in the production. Meenyon has a dedicated team of supervisors, material managers and operations personnel.

· We will make a clear plan to go global. We will do research on the targeted markets, learn the facts about them, and master and basic expressions in their languages. We believe this will help us have a better understanding of them before we get down to cooperation.


Product Details

In the production, Meenyon believes that detail determines result and quality creates brand. This is the reason that we strive for excellence in every product detail.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
