Factory Direct Walk Behind Pallet Lift Distributor
Product details of the walk behind pallet lift
Quick Detail
Meenyon's walk behind pallet lift emphasizes the value of innovation and design. Product quality meets industry standards and has passed international certification. Meenyon has built a comprehensive, professional and thoughtful walk behind pallet lift solutions for its customers.
Product Information
Our walk behind pallet lift has a certain share in the market because of the following characteristics.
Product specifications
| Item | Name | Unit (Code) | ||
| Feature | ||||
| 1.1 | Brand | MEENYON | MEENYON | |
| 1.2 | Model | ES12-12ES | ES10-10ES | |
| 1.3 | Power | Electric | Electric | |
| 1.4 | Operation | Walking | Walking | |
| 1.5 | Rated load | Q (kg) | 1200 | 1200 |
| 1.6 | Load center distance | c (mm) | 600 | 600 |
| Weight | ||||
| 2.1 | Dead weight (incl. battery) | kg | 661 | 540 |
| Size | ||||
| 4.2 | Lowest height after the gantry is lowered | h1 (mm) | 2056 | 2026 |
| 4.4 | Standard max lifting height | h3 (mm) | 3015 | 3015 |
| 4.15 | Fork drop height | h13(mm) | 88 | 88 |
| 4.19 | Overall length | l1 (mm) | 1740 | 1740 |
| 4.21 | Overall width | b1/ b2 (mm) | 800 | 800 |
| 4.25 | Fork outside distance | b5 (mm) | 570 | 570 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2225 | 2225 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2150 | 2150 |
| 4.35 | Turning radius | Wa (mm) | 1408 | 1408 |
| Performance parameter | ||||
| 5.1 | Walk speed, full /no load | km/ h | 4 / 4.5 | 4 / 4.5 |
| 5.2 | Lifting speed, full /no load | m/ s | 0.12/0.22 | 0.12/0.22 |
| Motor, Power unit | ||||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 2*12V/105Ah | 2*12V/105Ah |
Company Information
Meenyon is a Chinese company specializing in design, production and sales of walk behind pallet lift. Based on the outstanding end-to-end service support, we have been replete with a large customer base. The customers from around the world have been cooperating with us for years since the first order. Meenyon always adjusts itself to match the requirements of consumers. Ask online!
We hope to cooperate with you for a win-win situation and jointly create a better future.
