Product specifications
Item | Name | Unit (Code) | ||
Feature | ||||
1.1 | Brand | MEENYON | MEENYON | |
1.2 | Model | ES10-22DM | ES12-25DM | |
1.3 | Power | Electric | Electric | |
1.4 | Operation | Walking | Walking | |
1.5 | Rated load | Q (kg) | 1000 | 1200 |
1.6 | Load center distance | c (mm) | 600 | 600 |
Weight | ||||
2.1 | Dead weight (incl. battery) | kg | 676 | 676 |
Size | ||||
4.2 | Lowest height after the gantry is lowered | h1 (mm) | 2086 | 2086 |
4.4 | Gantry travel | h3 (mm) | 2980 | 2980 |
4.4... | Gantry lifting height (fork face to ground) | h23 (mm) | 2920 | 2920 |
4.15 | Fork drop height | h13(mm) | 60 | 60 |
4.19 | Overall length | l1 (mm) | 1650 | 1650 |
4.21 | Overall width | b1/ b2 (mm) | 1135/1235/1335/1435 | 1135/1235/1335/1435 |
4.25 | Fork outside distance | b5 (mm) | 200~780 | 200~780 |
4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2255 | 2255 |
4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2180 | 2180 |
4.35 | Turning radius | Wa (mm) | 1404 | 1404 |
Performance parameter | ||||
5.1 | Walk speed, full /no load | km/ h | 4 / 4.5 | 4 / 4.5 |
5.2 | Lifting speed, full /no load | m/ s | 0.12/0.22 | 0.12/0.22 |
Motor, Power unit | ||||
6.4 | Battery voltage/nominal capacity | V/ Ah | 2*12V/105Ah | 2*12V/105Ah |
Company Advantages
· The Meenyon best electric forklift brand is fabricated by our deft professionals.
· The product is quality assured as it has undergone numerous rigorous tests before coming into the market.
· This offered products is widely known among clients owing to all these features.
Company Features
· Meenyon occupies the leading position in the best electric forklift brand industry.
· We were awarded as 'Trustworthy and Honesty Group' and 'China Well-Known Trademark'. These awards further proofs that we are a capable enterprise in manufacturing and supplying best electric forklift brand.
· Meenyon will carry out everlasting innovation and exploration centered on customer’s demand. Get more info!
Application of the Product
best electric forklift brand of Meenyon is widely used and has a wide range of applications.
Meenyon insists on providing customers with one-stop overall solution from the customer's point of view.
