Company Advantages
· The design of electric hand pallet truck has been further strengthened.
· Our professional quality check team conducts strict quality inspections for the sake of high quality.
· With its cost-effective products, standardized market operations, good after-sales service, Meenyon enjoys a high reputation in the field.
SMALL AND FLEXIBLE
◆ Exquisite and compact body structure allows for flexible operation in narrow spaces.
◆ Turning radius is only 1340MM.
STRONG POWER
◆ Driven by 48V900W, with a load of 2T and a climbing speed of 6%. The compact model also has a powerful power supply.
Superior performance
High performance accessories.
◆ Standard upright walking. Flexible and comfortable handling, while saving steering space.
◆ Standard power meter, fault indication, etc. Intuitive and clear display, convenient and worry free homework.
◆ Equipped with a full surround drive cover. Under the premise of ensuring safety, greatly improve the passability and meet the usage needs of more complex working conditions.
COMPANY STRENGTH
| Item | Name | Unit (code) | |
| Feature | |||
| 1.1 | Brand | MEENYON | |
| 1.2 | Model | EPA205Z | |
| 1.3 | Power | Electric | |
| 1.4 | Operation | Walking | |
| 1.5 | Rated load | Q (kg) | 2000 |
| 1.6 | Load center distance | c (mm) | 600 |
| Weight | |||
| 2.1 | Dead weight (incl. battery) | kg | 195 |
| Tires, chassis | |||
| 3.2 | Front wheel size (diameter × width) | Ф210x70 | |
| Size | |||
| 4.4. | Standard max lifting height | h3 (mm) | 110 |
| 4.15 | Fork drop height | h13(mm) | 80 |
| 4.19 | Overall length | l1 (mm) | 1550 |
| 4.21 | Overall width | b1/ b2 (mm) | 620（695） |
| 4.25 | Fork outside distance | b5 (mm) | 560（685） |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2155 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2060 |
| 4.35 | Turning radius | Wa (mm) | 1340 |
| Performance parameter | |||
| 5.1 | Walk speed, full/no load | km/ h | 4.5/5 |
| 5.8 | Max climb, full/no load | % | 6 /16 |
| Motor, Power unit | |||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 12*4/26 |
Company Features
· Meenyon is praised as one of the most competitive enterprises that focus on the R&D, production, and marketing of electric hand pallet truck.
· Meenyon has a complete system for QC.
· Meenyon strictly guarantees the quality of the service. Ask online!
Product Details
We are confident about the exquisite details of electric hand pallet truck.
