Hydrogen Forklift Trucks

Inquiry

Send your inquiry

Product details of the hydrogen forklift trucks

Quick Detail

Meenyon hydrogen forklift trucks is designed by using the finest material and leading technology. The product has been subject to thorough tests to ensure that it is excellent in quality, performance, functionality, etc. hydrogen forklift trucks of Meenyon can play a role in various industries. This product has high commercial value and has broad market application prospects.

Product Description

Supported by advanced technology, our hydrogen forklift trucks has a greater breakthrough in the comprehensive competitiveness of the products, as shown in the following aspects.

Fuel Cell Stack 200W

Additional Information

Horizon Educational highly recommends filling out a quote request form. By doing this we can reach out to you and help you determine what fuel cell stack accessories you made need for faster integration of this fuel cell stack into your project. Please click here to fill out the form. However, if you feel more comfortable, then you may purchase just the standalone fuel cell stack.

200W Fuel Cell and Hydrogen

◆ Safety Requirements

Do not connect or disconnect power cables when the fuel cell stack is turned on. Warranty is void if the fuel cell stack is disassembled or otherwise altered. Hydrogen is a colorless, odorless, and flammable substance. Always operate and store the fuel cell stacks and hydrogen storage canisters in an area with ample ventilation. Fuel cell systems should always be equipped with a highly accurate hydrogen sensor to detect any leaking hydrogen within the system or from the hydrogen storage canister. Please refer to the H-200 User Manual to see a complete list of the safety requirements for the product.

Fuel Cell Stack 200W Quick Product Facts

Number Of Cells

This fuel cell stack is composed of 40 fuel cells.

Hydrogen Pressure

Hydrogen must be fed into the fuel cell stack at a pressure of 0.45-0.55 Bar.

Ambient Temperature

The fuel cell stack operates best in a temperature ranging from 41 to 86° F / 5-30° C.

Humidification

This fuel cell stack uses self-humidification.

FC Stack Weight

The stack (including fan and casing) weighs 4.91lbs / 2,230g.

Controller Weight

The weight of the controller is 0.88lb / 400g.

System Efficiency

At 24 volts the efficiency of the system is 40%.

External Power Supply

Proper operation of the stack requires an external power supply of 13 volts at 5 amperes.

Packing Information

VL-05	VL-10	VL-30	VL-40	VL-65	VL-100	VL-120
System rated power output (kW) *	5	10	30	40	65	100	120	*does not include cooling fan power and boost DC efficiency
Stack rated power output (kW)	6	12	36	53	79	120	150
Number of cells	65	90	150	220	330	500	500
Operating ambient temperature (℃)	-10 to +40	-10 to +40	-30 to +45	-30 to +45	-30 to +45	-30 to +45	-30 to +45
Storage ambient temperature (℃)	-40 to +60	-40 to +60	-40 to +60	-40 to +60	-40 to +60	-40 to +60	-40 to +60
Operating ambient humidity (%)	0 to 95	0 to 95	0 to 95	0 to 95	0 to 95	0 to 95	0 to 95
Operating pressure (kPa)	up to 50	up to 50	80 to 100	80 to 100	80 to 100	80 to 100	120 to 150
IP rating	IP54	IP54	IP67	IP67	IP67	IP67	IP67
Vibration noise (dB)	up to 80	up to 80	up to 78	up to 78	up to 78	up to 78	up to 90
Voltage current output	125A@48V	222A@54V	400A@90V	400A@132V	400@198V	400@300V	500A@300V
System dimensions (mm) **	630 x 560 x 610	630 x 560 x 610	742 x 686 x 637	890 x 600 x 520	970 x 600 x 516	1200 x 790 x 520	1200 x 680 x 630	** radiator, touch screen, booster DC or air compressor not included
System weight (kg) ***	170	180	135	145	170	238	290	*** booster DC not included
DC output voltage (V)	48	48/80
Boost DC output voltage (V)			300 to 450	500 to 700	500 to 700	500 to 700	500 to 700
System mass power density (W/kg) ****			220	275	382	420	505	*** booster DC not included
Fuel cell stack volume ratio power (kW/l)							3.5
Stack operating temperature (℃)	60 to 70	60 to 70	70 to 85	70 to 80	70 to 80	70 to 80	70 to 85
H2 purity (% dry hydrogen)	99,97	99,97	99,97	99,97	99,97	99,97	99,97
Average H2 consumption at rated power (m3/kWh)			up to 0,73	up to 0,73	up to 0,73	up to 0,73	up to 0,73
Fuel Cell efficiency at rated power (%)	at least 42	at least 42	at leas 47,8	at least 47,8	at least 47,8	at least 47,8	at least 47,8
Hydrogen inlet pressure (Mpag)	0,6 to 1.0	0,6 to 1.0	1,1 to 1,3	1,1 to 1,3	1,1 to 1,3	1,1 to 1,3	1,1 to 1,3

Company Advantages

As a modern enterprise, Meenyon has a combined business mode in R&D, production, trade and service. Our main product is Meenyon persists in the tenet of 'value, integrity, cooperation and mutual benefit' and strives to become the most influential enterprise in China. Meenyon has a high-quality management team integrating technology development, product R&D, and market expansion, which provides solid backing for rapid corporate development. Meenyon has been engaged in the production of for many years and has accumulated rich industry experience. We have the ability to provide comprehensive and quality solutions according to actual situations and needs of different customers.
Our products are available in various types and reasonable price. Welcome people from all walks of life to inquire and discuss business.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
