Meenyon offers professional OEM & ODM services for all kinds of electric forklift, electric pallet truck, electric stacker and diesel forklift.

Meenyon Brand Electric Tow Tractor for Sale Supplier 1
Meenyon Brand Electric Tow Tractor for Sale Supplier 2
Meenyon Brand Electric Tow Tractor for Sale Supplier 3
Meenyon Brand Electric Tow Tractor for Sale Supplier 4
Meenyon Brand Electric Tow Tractor for Sale Supplier 5
Meenyon Brand Electric Tow Tractor for Sale Supplier 1
Meenyon Brand Electric Tow Tractor for Sale Supplier 2
Meenyon Brand Electric Tow Tractor for Sale Supplier 3
Meenyon Brand Electric Tow Tractor for Sale Supplier 4
Meenyon Brand Electric Tow Tractor for Sale Supplier 5

Meenyon Brand Electric Tow Tractor for Sale Supplier

Inquiry

Product details of the electric tow tractor for sale


Quick Overview

The supreme master of detailed design of electric tow tractor for sale has gained much more fame for Meenyon. It quality is guaranteed by internationally advanced production equipment and technology. electric tow tractor for sale can be applied to different industries, fields and scenes. The product is well-received in the global market and enjoys a bright market prospect.


Product Description

More details of electric tow tractor for sale are shown as follows.

Introduction

Pro4-xj1
New design
◆ Equipped with lithium battery, recharge and use, easy to replace ◆ High torque electromagnetic brake, safe and effective
Pro4-xj2
Lighter
◆ Lighter, narrower and smaller body for different working conditions ◆ Compact overall design, cost-effective, best to meet user needs ◆ The operation is flexible and convenient, and the battery lasts longer

Convenient And Comfortable Operation

◆  Operation handle four-way adjustment, more comfortable operation


◆  The rear backrest is adjustable up and down, suitable for drivers of different sizes


◆  Standing operation is convenient for loading and unloading


◆  Adopt the handling car handle, endless speed change, easy to use

Pro4-xj3

COMPANY STRENGTH

Item

Name

Unit (Code)



Feature







1.1 Brand   MEENYON
1.2 Model   QDD151T
1.3 Power   Electric
1.4 Operation   Standing
1.5 Rated load Q (kg) 1500

Weight







2.1 Dead weight (incl. battery) kg 150

Tires, chassis







3.1 Tire type, drive wheel/carrier wheel (steering wheel)   Pneumatic tire/Solid tire
3.2 Front wheel size (diameter × width)   2x Ф250x85

Size







4.8 Height of seats and platforms h7 (mm) 120
4.9 Minimum/maximum height of operating position handle lever h14 (mm) 1130~1340
4.12 Height of traction coupler h10(mm) 123/146/169
4.19 Overall length l1 (mm) 1280.5
4.21 Overall width b1/ b2 (mm) 620
4.35 Turning radius Wa (mm) 1270

Performance parameter







5.1 Walk speed, full/no load km/ h 4.5/5
5.5 Traction, full/no load N 300
5.6 maximum traction force,full/no load N 466
5.7 Climb, full load/no load % 3 / 16
5.10. Service brake type   electromagnetism

 Motor, Power unit







6.1 Rated power of drive motor S2 60min kW 0.8
6.4 Battery voltage/nominal capacity V/ Ah 24/20

Drive/lifting mechanism







8.1 Drive Control Type   DC

Other parameters







10.5 Steering type   mechanical
10.7 Noise level dB (A) 70
10.8 Traction coupling, according to DIN15170 type   Pin type


Company Advantages

After so many years of dedication in manufacturing electric tow tractor for sale, Meenyon becomes an expert and has the confidence to become a leader in this field. Meenyon possesses first-class production capacity in electric tow tractor for sale industry. Meenyon will try its best to achieve sustainable development.
With rich experience and exquisite technology, we are looking forward to building good cooperation with partners from all walks of life and creating a better tomorrow!

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
