Product specifications
| Item | Name | Unit (Code) | |||
| Feature | |||||
| 1.1 | Brand | MEENYON | MEENYON | MEENYON | |
| 1.2 | Model | ES14-14WA | ES16-16WA | ES12-12WA | |
| 1.3 | Power | Electric | Electric | Electric | |
| 1.4 | Operation | Walking | Walking | Walking | |
| 1.5 | Rated load | Q (kg) | 1400 | 1600 | 1200 |
| 1.6 | Load center distance | c (mm) | 600 | 600 | 600 |
| Weight | |||||
| 2.1 | Dead weight (incl. battery) | kg | 1050 | 1070 | 950 |
| Size | |||||
| 4.2 | Lowest height after the gantry is lowered | h1 (mm) | 2030 | 2030 | 1970 |
| 4.4 | Standard max lifting height | h3 (mm) | 2912 | 2912 | 2912 |
| 4.15 | Fork drop height | h13(mm) | 88 | 88 | 88 |
| 4.19 | Overall length | l1 (mm) | 1940 | 1940 | 1940 |
| 4.21 | Overall width | b1/ b2 (mm) | 800 | 800 | 800 |
| 4.25 | Fork outside distance | b5 (mm) | 550/685 | 550/685 | 550/685 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2465 | 2465 | 2465 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2440 | 2440 | 2440 |
| 4.35 | Turning radius | Wa (mm) | 1589 | 1589 | 1589 |
| Performance parameter | |||||
| 5.1 | Travel speed, full / no load | km/ h | 5.0/5.5 | 5.0/5.5 | 5.0/5.5 |
| 5.2 | Max climb, full / no load | m/ s | 0.13/0.16 | 0.13/0.16 | 0.13/0.16 |
| Motor, Power unit | |||||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 24V/210Ah | 24V/230Ah | |
Company Advantages
· The quality and safety of all the materials used for Meenyon electric stacker forklift are extremely important.
· The product is unmatched in performance, service life and usability.
· The raw materials of Meenyon electric stacker forklift are procured from recognized vendors.
Company Features
· Meenyon specializes in the research, development, production and market of electric stacker forklift products.
· We have brought together a team of professional manufacturing members. With their years of experience in the manufacturing process and a deep understanding of our products, they allow us to provide products exactly meeting customers' requirements.
· Meenyon believes it will grow into the first brand of world's electric stacker forklift. Please contact us!
Application of the Product
electric stacker forklift of Meenyon can be widely used in various fields.
With a focus on customers, Meenyon analyzes problems from the perspective of customers and provides comprehensive, professional and excellent solutions.
