Product details of the electric straddle pallet stacker
Product Information
In terms of design, electric straddle pallet stacker extracts the essence of simplicity. The supplied product can always be serviced in the best conditions. These offered products are widely demanded in the market.
Product specifications
Item | Name | Unit (Code) | |
Feature | |||
1.1 | Brand | MEENYON | |
1.2 | Model | ESR181 | |
1.3 | Power | Electric | |
1.4 | Operation | Walking | |
1.5 | Rated load | Q (kg) | 1800 |
1.6 | Load center distance | c (mm) | 500 |
Weight | |||
2.1 | Dead weight (incl. battery) | kg | 780 |
Size | |||
4.2 | Lowest height after the gantry is lowered | h1 (mm) | 1731 |
4.4 | Standard max lifting height | h3 (mm) | 2430 |
4.15 | Fork drop height | h13(mm) | 90 |
4.19 | Overall length | l1 (mm) | 1854 |
4.21 | Overall width | b1/ b2 (mm) | 852 |
4.25 | Fork outside distance | b3 (mm) | 570 |
4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2700 |
4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2653 |
4.35 | Turning radius | Wa (mm) | 1848 |
Performance parameter | |||
5.1 | Travel speed, full / no load | km/ h | 4.5/5.0 |
5.2 | Max climb, full / no load | m/ s | 0.14/0.2 |
5.8 | Max climb, full/no load | % | |
Motor, Power unit | |||
6.4 | Battery voltage/nominal capacity | V/ Ah | 48/65 |
Company Feature
• Meenyon's products not only sell well in China but also have a certain market share in many foreign countries.
• Meenyon was founded in After the development for we have become a leader in the industry.
• To meet the huge demands of customers, our company has formed a sound service system to provide consumers with quality products and services.
Leave your contact information, and Meenyon will provide you with details of customized products.
