Oem Forklift - - Meenyon
Product details of the oem forklift
Product Description
The color scheme of oem forklift makes it more harmonious and more colorful. Strict quality tests are conducted to ensure longevity and cost effectiveness of this offered product. Meenyon strives to grasp the trend of industrial development and accelerate the transformation of innovation.
Product specifications
| Item | Name | Unit (Code) | ||||
| Feature | ||||||
| 1.1 | Brand | MEENYON | MEENYON | MEENYON | MEENYON | |
| 1.2 | Model | ICE302B2 | ICE252B2 | ICE352B2 | ICE322B2 | |
| 1.3 | Power | Electric | Electric | Electric | Electric | |
| 1.4 | Operation | Car type | Car type | Car type | Car type | |
| 1.5 | Rated load | Q (kg) | 3000 | 2500 | 3500 | 3200 |
| 1.6 | Load center distance | c (mm) | 500 | 500 | 500 | 500 |
| Weight | ||||||
| 2.1 | Dead weight (incl. battery) | kg | 4080 | 3770 | 4560 | 4270 |
| Tires, chassis | ||||||
| 3.1 | Tire type, drive wheel/carrier wheel (steering wheel) | Pneumatic tire | Pneumatic tire | Pneumatic tire | Pneumatic tire | |
| Size | ||||||
| 4.4 | Max lifting height of standard frame | h3 (mm) | 3000 | 3000 | 3000 | 3000 |
| 4.7 | Top guard (cab) height | h6 (mm) | 2160 | 2160 | 2190 | 2160 |
| 4.20. | Length to vertical face of fork | l2 (mm) | 2665 | 2503 | 2726 | 2726 |
| 4.21 | Overall width | b1/ b2 (mm) | 1230 | 1154 | 1230 | 1230 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 4118 | 3985 | 4170 | 4170 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 4318 | 4195 | 4370 | 4370 |
| 4.35 | Turning radius | Wa (mm) | 2437 | 2290 | 2484 | 2484 |
| Performance parameter | ||||||
| 5.1 | Travel speed, full / no load | km/ h | 11 / 12 | 11 / 12 | 11 / 12 | 11 / 12 |
| 5.8 | Max climb, full / no load | % | 15/15 | 15/15 | 15/15 | 15/15 |
| Motor, Power unit | ||||||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 80/205 | 80/150 | 80/280 | 80/205 |
advantage
product display
Company Advantage
• Meenyon, founded in has a development history of years.
• Meenyon's are deeply trusted by customers. They occupy a large market share in China and are exported to Europe, America, Southeast Asia, and other countries and regions.
• We always persevere in the principle of 'customer first, service first'. According to customer's different needs, we provide relevant solutions and offer a good service experience to customers.
• Meenyon has an elite team with high cohesiveness and technical skills, which provides favorable conditions for the development.
If you have any suggestions on Meenyon's leave your contact information. We will get back to you as soon as possible!
