Product details of the stand on stacker
Quick Overview
The technical production standard of Meenyon stand on stacker far exceeds the market average. This product is vigilantly examined by our quality testing department. Meenyon has gathered an experienced team with and strict management.
Product Introduction
We strive for perfection and pursue excellence in every detail of production. All this promotes the high quality of our products.
Product specifications
Item | Name | Unit (Code) | |
Feature | |||
1.1 | Brand | MEENYON | |
1.2 | Model | ESR181 | |
1.3 | Power | Electric | |
1.4 | Operation | Walking | |
1.5 | Rated load | Q (kg) | 1800 |
1.6 | Load center distance | c (mm) | 500 |
Weight | |||
2.1 | Dead weight (incl. battery) | kg | 780 |
Size | |||
4.2 | Lowest height after the gantry is lowered | h1 (mm) | 1731 |
4.4 | Standard max lifting height | h3 (mm) | 2430 |
4.15 | Fork drop height | h13(mm) | 90 |
4.19 | Overall length | l1 (mm) | 1854 |
4.21 | Overall width | b1/ b2 (mm) | 852 |
4.25 | Fork outside distance | b3 (mm) | 570 |
4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2700 |
4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2653 |
4.35 | Turning radius | Wa (mm) | 1848 |
Performance parameter | |||
5.1 | Travel speed, full / no load | km/ h | 4.5/5.0 |
5.2 | Max climb, full / no load | m/ s | 0.14/0.2 |
5.8 | Max climb, full/no load | % | |
Motor, Power unit | |||
6.4 | Battery voltage/nominal capacity | V/ Ah | 48/65 |
Company Advantages
Depending on the core strength of stand on stacker, Meenyon excels at developing, designing, and producing services in the industry. Meenyon owns internationally leading manufacturing equipment for stand on stacker. Customer satisfaction is Meenyon's eternal pursuit. Check now!
We sincerely welcome people from all walks of life to come to make cooperation, common development and a better future.
