Product selling points
Key points
◆ Outstanding reliability: High strength structure, mature drive and hydraulic system, reliable connectors and electrical parts
◆ Safe and secure: Fully anti-rollover tested, explosion-proof design of hydraulic system, automatically switches to slow speed mode after the forks raise to 720mm.
◆ Easier operation:Long handle, with independently developed handle mechanical spring structure, light operation, flexible steering;
Offset operation, greatly improve the operating field of view.
◆ Easier maintenance: Maintenance-free battery, automatic low voltage protection, self-diagnosis system
Application
◆ Small to Medium Workspaces: Ideal for performing stacking tasks in smaller warehouses or manufacturing facilities, providing an economical solution for material handling.
◆ Safety and Stability: Designed to offer high stability and safety, making it a hassle-free option for daily material handling needs.
COMPANY STRENGTH
| Item | Name | Unit (Code) | |
| Feature | |||
| 1.1 | Brand | MEENYON | |
| 1.2 | Model | EST122 | |
| 1.3 | Power | Electric | |
| 1.4 | Operation | Walking | |
| 1.5 | Rated load | Q (kg) | 1200 |
| 1.6 | Load center distance | c (mm) | 600 |
| Weight | |||
| 2.1 | Dead weight (incl. battery) | kg | 585 |
| Size | |||
| 4.2 | Lowest height after the gantry is lowered | h1 (mm) | 1856 |
| 4.4 | Standard max lifting height | h3 (mm) | 2430 |
| 4.15 | Fork drop height | h13 (mm) | 85 |
| 4.19 | Overall length | l1 (mm) | 1713 |
| 4.21 | Overall width | b1/ b2 (mm) | 792 |
| 4.25 | Fork outside distance | b5 (mm) | 570 |
| 4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 2290 |
| 4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 2225 |
| 4.35 | Turning radius | Wa (mm) | 1458 |
| Performance parameter | |||
| 5.1 | Travel speed, full / no load | km/ h | 4.2/4.5 |
| 5.2 | Lifting speed, full /no load | m/ s | 0.10/0.14 |
| Motor, Power unit | |||
| 6.4 | Battery voltage/nominal capacity | V/ Ah | 24/80 |
Company Advantages
· Meenyon electric walkie stacker is based on first-class, carefully selected and controlled raw materials.
· Our qualified team strictly implements checks on each testing procedure.
· For Meenyon, a good product should be supported with a better after-sale service.
Company Features
· Meenyon is a leading global provider of electric walkie stacker.
· Meenyon has been cultivating high-level scientific and technological talents with independent innovation capabilities to provide the best electric walkie stacker.
· To give each customer an unforgettable experience is the ultimate goal of Meenyon. Contact us!
Application of the Product
Meenyon's electric walkie stacker is widely used in various scenes.
Meenyon always adheres to the service concept to meet customers' needs. We are committed to providing customers with one-stop solutions that are timely, efficient and economical.
