Pull the battery sideways to replace the battery, and the power comes in instantly.
(Optional battery capacity)
1. The whole vehicle adopts the high-strength box-type frame of an internal combustion vehicle, which can meet the harsh outdoor working conditions.
2. The entire vehicle is IPX4 waterproof and supports all-weather use indoors and outdoors.
3. High ground clearance, can go off-road, and can easily pass through uneven potholes.
4. Wide field of view mast, good front working field of view, does not affect driving sight, making operation efficient and safe
It has strong load capacity and can meet the needs of 3.8 tons heavy cargo handling in the logistics park.
It uses lower carbon, cleaner and more environmentally friendly lithium electric power. Compared with internal combustion vehicles, it has low noise, no dirty exhaust gas, and no acid mist. It meets the needs of indoor use and is beneficial to the health of employees.
1. The reinforced mast is adopted, the rollers are improved, the material is thicker, the load capacity is stronger, and the overall performance is good.
2. The vehicle has a low center of gravity and strong stability, and is suitable for handling goods with large load center distances and attachment operations.
3. Use mature front and rear axles, lifting hydraulics and control systems and other common parts for internal combustion vehicles, which are strong and durable.
4. The entire vehicle is equipped with parking, emergency power-off and other protections for safe driving.
1. The engine cover can be opened at a wide angle for easy maintenance and battery replacement.
2. Lithium batteries are maintenance-free and require less maintenance costs.
3. 5-year lithium battery warranty, lithium iron phosphate battery is highly safe
1. Taking advantage of the lithium battery, the driving space is large and the operation is comfortable.
2. The steering wheel is adjustable to suit drivers with different body shapes and operating habits.
3. The steering system has been finely adjusted, making the turns smooth.
COMPANY STRENGTH
Item | Name | Unit | |||
---|---|---|---|---|---|
Feature | |||||
1.1 | Brand | MEENYON | MEENYON | MEENYON | |
1.2 | Model | EFX302H Lithium | EFX352H Lithium | EFX382H Lithium | |
1.3 | Power | Electric | Electric | Electric | |
1.4 | Operation | Car type | Car type | Car type | |
1.5 | Rated load | Q (kg) | 3000 | 3500 | 3800 |
1.6 | Load center distance | c (mm) | 500 | 500 | 500 |
Weight | |||||
2.1 | Dead weight (incl. battery) | kg | 4530 | 4745 | 5210 |
Tires, chassis | |||||
3.1 | Tire type, drive wheel/carrier wheel (steering wheel) | Pneumatic tire | Pneumatic tire | Solid tire | |
Size | |||||
4.4 | Max lifting height of frame | h3 (mm) | 3000 | 3000 | 3000 |
4.7 | Top guard (cab) height | h6 (mm) | 2160 | 2190 | 2190 |
4.20 | Length to vertical face of fork | l2 (mm) | 2726 | 2765 | 2800 |
4.21 | Overall width | b1/b2 (mm) | 1230 | 1230 | 1230 |
4.34.1 | Pallet 1000 × 1200 cross path width | Ast (mm) | 4170 | 4216 | 4256 |
4.34.2 | Pallet 800 × 1200 cross path width | Ast (mm) | 4370 | 4416 | 4456 |
4.35 | Turning radius | Wa (mm) | 2484 | 2530 | 2570 |
Performance parameter | |||||
5.1 | Travel speed, full / no load | km/ h | 11/12 | 11/12 | 15/16 |
5.8 | Max climb, full / no load | % | 18/24 | 17/23 | 16/20 |
Motor, Power unit | |||||
6.4 | Battery voltage/nominal capacity | V/ Ah | 80/280 | 80/280 | 80/280 |
Company Advantages
· The design style of Meenyon forklift wholesalers can be varied according to different requirements.
· The product has to be subjected to stringent quality checks to ensure premium quality before shipment.
· Meenyon has established a good social image in development.
Company Features
· Meenyon has been producing and offering high-quality forklift wholesalers for years. Our competence and experience in this industry are well-known.
· With rich R&D experience, Meenyon has done a good performance in launching new products.
· Our goal is to be a global leader. We believe that we can provide the ideal elements in our value chain to achieve the best interests of each customer. Get more info!
Application of the Product
Meenyon's forklift wholesalers can meet the different needs of customers.
Meenyon is able to meet customers' needs to the greatest extent by providing customers with one-stop and high-quality solutions.
